MONO Turbo KIT

This Mono-Meter measures EGT and and Boost.

The units are simple and small with powerful features.

Can be used as a diagnostic tool for fault finding of temperature and pressure.

Main Features:

• 1 Mechanical Boost Input (Max 2Bar / 30psi)
• 1 EGT input – Uses Madman TP100 probe
• 2 External preset sensor inputs for Madman MPS2 (2Bar / 30psi and MPS5 (5Bar / 70psi) sensors.
• Min/Max Display
• Data logging to .csv file for all 4 channels.
• Download log file via wi-fi
• The units do not contain any alarm functions.

Applications:

• Before and After Turbo boost pressure assessment
• Fuel supply and return pressure assessment
• Coolant pressure assessment
• Hydraulic systems
• Engine and Autobox oil
• Engine oil and air filter restrictions and other vacuum circuits like brakes.

Additional Options:

• If more pressure measurements are needed, you can purchase 2 additional Madman Pressure Senders 2 bar, and 5 Bar (part numbers MPS2, MPS5).

What you get in the box:

• 1x MONO Turbo unit
• 1x EGT probe
• 1x Brass Tee Piece
• 1x pu tube
• 1x 4-6mm adapter

Standard features:

• Multi-Colour display screen with 2 control buttons
• Data Logging of all inputs to internal memory, downloadable to your mobile phone
• Max and Min Value display with reset
• Wide input voltage range for 12 or 24V applications
• Polarity protection for reverse polarity and over voltage
• Flash upgradable via your phone or pc
• 1 Year limited Warranty
